HAWEN QT15 Fully Automatic Block Production Line Shipped to Customer in UAE

HAWEN QT15 fully automatic block production line shipped to UAE customer

UAE CUSTOMER PROJECT

HAWEN QT15 Fully Automatic Block Production Line Shipped to Customer in UAE

From supplying block moulds for the customer's existing MASA equipment to delivering a complete QT15 automatic production line, this shipment marks another important milestone in our long-term cooperation.

LONG-TERM PARTNERSHIP

From Mould Cooperation to a Complete Production Line

Every successful project begins with trust. For this UAE customer, that trust was established through years of successful cooperation before the QT15 production line project began.

Existing MASA Equipment

The customer has been operating a MASA 9.1 XL block making machine for many years.

Previous Mould Cooperation

Before purchasing the QT15 line, the customer had already ordered multiple hollow block moulds and paver moulds from HAWEN for their MASA equipment.

Trust Built Over Time

The proven performance of our moulds allowed the customer to experience HAWEN's manufacturing quality, technical capability and service support firsthand.

HAWEN QT15 automatic block making machine production and factory inspection

FACTORY VISIT

Customer Inspection Before Placing the Order

Before making the final purchasing decision, the customer visited our factory to evaluate HAWEN's manufacturing capabilities and discuss the project directly with our engineering team.

During the visit, the customer inspected our workshop, reviewed the production process and discussed their production requirements and complete line configuration.

After comparing several suppliers, the customer ultimately selected HAWEN Machinery for our reliable equipment, professional technical support and comprehensive service.

QT15 PRODUCTION CAPACITY

1400 × 1200 mm Large Pallet for High-Output Production

The QT15 block making machine is designed for large-scale concrete product manufacturing, combining a large forming area with efficient production cycles for hollow blocks and concrete pavers.

400 × 200 × 200 MM

Hollow Block

2,700 pcs/hour

15 pcs/mould
21,600 pcs / 8-hour shift

400 × 150 × 200 MM

Hollow Block

3,240 pcs/hour

18 pcs/mould
25,920 pcs / 8-hour shift

200 × 100 × 60 MM

Concrete Paver

9,720 pcs/hour

54 pcs/mould
77,760 pcs / 8-hour shift

FULLY AUTOMATIC SOLUTION

A Complete Integrated Block Production Line

The QT15 project combines the main block making machine with automatic handling and cubing equipment to create an integrated production system from block forming to finished-product stacking.

01 / FORMING

Automatic Block Making Plant

High-efficiency forming and compaction for hollow blocks, pavers and other concrete products.

02 / HANDLING

Elevator & Lowerator

Automatic handling of production pallets before and after the curing process.

03 / TRANSFER

Finger Car System

Automated pallet transfer between the production line and curing area.

04 / CUBING

Automatic Block Cuber

Automatic stacking of finished products for efficient storage and transportation.

FACTORY TESTING

Complete Trial Production Before Shipment

Before shipment, the complete production line was assembled and commissioned at our factory for trial production.

HAWEN engineers carefully tested and adjusted the major systems to ensure that every unit could operate smoothly as one integrated production line.

Hydraulic system
Vibration system
Electrical control
Automatic handling
Production testing
System coordination

QT15 block production line trial production and factory testing

SUCCESSFULLY SHIPPED

QT15 Production Line Is Now On Its Way to the UAE

After successfully completing trial production and final inspection, the complete production line was approved for delivery, carefully packed and shipped from our factory.

HAWEN QT15 block production line shipped from Shanghai to Jebel Ali Port UAE

From HAWEN Factory to Jebel Ali Port

The equipment was transported from our factory to Shanghai, where it was loaded onto a bulk vessel for sea transportation to Jebel Ali Port, UAE.

This shipment represents more than the delivery of a new production line. The cooperation has grown from supplying multiple moulds for the customer's existing MASA 9.1 XL equipment to supplying a complete HAWEN QT15 fully automatic block production line.

HAWEN Factory → Shanghai → Bulk Vessel → Jebel Ali Port, UAE

CONTINUED SUPPORT

Shipment Completed, Service Continues

Although the production line has already left our factory, HAWEN's support continues through the next stages of the project.

Installation

Professional technical guidance for the installation of the complete production line.

Commissioning

Technical support for equipment adjustment and system commissioning after installation.

Production Startup

Support during production startup to help the customer put the new line into operation smoothly and efficiently.

Built on Trust. Delivered for Long-Term Production.

From supplying precision moulds to delivering a complete QT15 fully automatic block production line, this UAE project reflects the long-term cooperation between HAWEN Machinery and our customer. We look forward to seeing the new production line successfully installed and creating lasting value for the customer's concrete product business.
